S7-Wi-Fi Notes W Know Domain

Processor:

goke7202v300

Image sensor:

Front GC2053/GC2083

Lens:

Four or six sets of all-glass lenses

Aperture:

F1. 8

Diagonal:

120 ° wide angle

Maximum video resolution:

2304*1296

Encoding resolution specifications:

'Support 2304*1296 s 1920x1080

Video encoding format:

H.264 encoding, H. 265 encoding MP4 format storage

Valid pixels:

Maximum 3 million

Photo Format:

JPEG（1080P）

Collision sensor:

three-axis acceleration sensor

Hardware Parameters

Recording mode:

Loop video does not miss seconds

Screen

LCD screen (optional)

Storage:

TF card (Class 10 or above, maximum support 128G)

Start Time:

1S

Operating voltage:

5V/12V optional

Operating current:

170mA (typical)(DC 12V)

Quiescent current:

Storage temperature (VII):

(-30 Seven -80 Seven)

Operating temperature (VII):

(-15 Seven -70 Seven)

Operating humidity (VII):

15%-60%RH

Battery Type:

Button cell ML621 (optional)

Wide Voltage Adaptive:

Adapt to in-car power supply environment (5V/12V)

Soft

Chinese voice control:

Support (optional)

Piece

English voice control:

Support (optional)

Reference

Power off video save:

Support (MP4 power-up repair again)

Number

Parking monitoring (reduced time video):

Support (protection voltage 11.8V)
